ToolkitRC M8AC 200/600W
Product detailed description
ToolkitRC M8AC is a versatile dual-channel charger that strikes the perfect balance between compact size and high power. With its integrated power supply, it is ready for immediate use anywhere, offering advanced battery management functions and modern connectivity for charging secondary devices.
- Dual AC/DC Input: The charger supports direct wall outlet power (AC 100–240V) with 200W output, or external DC power (7–30V) to unlock a total power of up to 600W.
- Two Independent Channels: Charge two different batteries simultaneously. In DC mode, each channel provides up to 300W, significantly reducing downtime between sessions.
- High Balance Current: With an 800mA balance current per cell, it ensures fast and precise voltage leveling, which extends the lifespan of your LiPo batteries.
- USB-C Fast Charge: The built-in USB-C port with 65W Power Delivery (PD) allows for rapid charging of laptops, smartphones, or radios directly from the charger.
- IPS Color Display: The 2.4" high-resolution display with wide viewing angles provides a real-time overview of all charging parameters, even in bright conditions.
- Multifunctional Tool: Beyond charging, the M8AC serves as a voltage meter, internal resistance tester, and a programmable DC power supply.
Technical Specifications
- Input Voltage: AC 100–240V / DC 7–30V (max. 30A)
- Charging Power (AC): 200W total
- Charging Power (DC): 2x 300W (asynchronous) / 1x 600W (synchronous)
- Charging Current: 0.1–15A per channel (up to 25A synchronous)
- Discharge Power: 15W per channel (Recycle mode up to 600W)
- Battery Support: LiPo, LiHV, LiFe, Li-ion, LTO (1–6S), NiMH (1–16S), Pb (1–10S)
- Balance Current: 800mA (accuracy < 0.005V)
- USB-C Output: 65W (PD, QC, AFC, FCP, SCP)
- Dimensions & Weight: 110x110x50 mm, 450 g
